Architecture¶

OpenPaw is a multi-workspace AI agent framework built on LangGraph (create_react_agent) and LangChain. This page covers system design, data flows, and architectural decisions for developers who want to understand, contribute to, or extend the framework.

System Overview¶

OpenPawOrchestrator manages a collection of WorkspaceRunner instances, each representing a fully isolated agent.

Each workspace runs as an independent asyncio task with its own:

Channel connection — a dedicated Telegram bot or other platform adapter
Message queue — lane-based FIFO with per-lane concurrency limits
Agent instance — LangGraph ReAct loop with composed middleware
Conversation database — AsyncSqliteSaver backed by SQLite, persists across restarts
Schedulers — cron jobs and heartbeat check-ins, each in the workspace timezone
Sandboxed filesystem — read/write access scoped to the workspace directory

OpenPawOrchestrator launches workspaces concurrently and coordinates graceful shutdown, including archiving active conversations. Workspaces share no state — a crash or misconfiguration in one cannot affect another.

Layered Architecture¶

OpenPaw enforces a stability contract: code dependencies flow downward only. Upper layers depend on lower layers; lower layers never import from above. This prevents circular imports and keeps the core data layer portable across framework changes.

        cli.py
           │
    runtime/orchestrator
           │
    workspace/runner  ──── channels/
           │           └── builtins/
       agent/runner    └── stores/
           │
        model/

The stability contract is enforced by convention: any import that flows upward is a design violation. model/ has no framework imports; core/ does not import from agent/ or workspace/; agent/ does not import from workspace/ or runtime/.

`openpaw/model/`¶

Pure dataclasses with no framework imports and no I/O. These are the types that flow through the entire system:

Message / MessageAttachment — unified representation of an inbound user event
Task / TaskStatus — cross-session task records for TASKS.yaml
SessionState — which conversation thread is active for a given session key
SubAgentRequest / SubAgentStatus — lifecycle tracking for spawned agents
DynamicCronTask — agent-scheduled task definition

Any layer can import from model/ without introducing a dependency cycle. These types are the shared vocabulary of the entire codebase.

`openpaw/core/`¶

Cross-cutting infrastructure used by all higher layers. Nothing in core/ imports from agent/, workspace/, or runtime/.

config/models.py — Pydantic models for GlobalConfig, WorkspaceConfig, CronDefinition, ProviderDefinition, and related nested structures
config/loader.py — Discovers workspace directories, loads YAML files, performs deep merge of global over workspace config
config/env_expansion.py — Expands ${VAR} tokens; fails fast with a descriptive error for unresolved references
config/providers.py — resolve_provider() maps a catalog provider name to a ResolvedProvider (model string, API key, region, extra kwargs)
timezone.py — workspace_now(tz) and format_for_display(dt, tz, fmt) implement the "store in UTC, display in workspace timezone" pattern
workspace.py — AgentWorkspace dataclass that assembles the XML-tagged system prompt from identity files and dynamic framework sections
utils.py — sanitize_filename(), deduplicate_path(), sanitize_error_for_user(), resolve_user_name()

`openpaw/agent/`¶

The LangGraph execution layer. AgentRunner wraps create_react_agent(), composes the middleware stack, and manages model instantiation via init_chat_model().

Key responsibilities:

Stitches AGENT.md, USER.md, SOUL.md, HEARTBEAT.md, and a dynamic <framework> section into the system prompt as XML-tagged blocks
Uses UsageMetadataCallbackHandler per invocation to capture input/output token counts, exposed via last_metrics
Exposes update_model() for live model switching without restarting the workspace or losing conversation state
Provides get_context_info() for context window utilization checks (used by auto-compact)

agent/middleware/ contains two middleware classes that use LangGraph's @wrap_tool_call decorator pattern:

QueueAwareToolMiddleware — calls queue_manager.peek_pending() before each tool call; in steer mode injects pending messages as next input; in interrupt mode raises InterruptSignalError
ApprovalToolMiddleware — checks whether the target tool is gated; if so, raises ApprovalRequiredError and stores a PendingApproval

agent/tools/ provides FilesystemTools — eight sandboxed operations (ls, read_file, write_file, overwrite_file, edit_file, glob_files, grep_files, file_info) restricted to the workspace root. sandbox.py exports resolve_sandboxed_path(), which rejects absolute paths, ~, .., and .openpaw/ access. This function is shared by SendFileTool and inbound processors for defense-in-depth validation.

agent/metrics.py provides InvocationMetrics (input/output/total tokens, LLM call count), thread-safe TokenUsageLogger (JSONL append to .openpaw/token_usage.jsonl), and TokenUsageReader for today/session aggregation using the workspace timezone day boundary.

`openpaw/workspace/`¶

Workspace lifecycle management — the layer that assembles all services into a running agent.

WorkspaceRunner is the central orchestrator for a single workspace. It initializes all services in order (load config → init channel → setup queue → load builtins → initialize checkpointer → schedule crons → start message loop), handles graceful shutdown (archive active conversations → close DB → stop channel), and dispatches lifecycle notifications.

MessageProcessor drives the main processing loop:

Dequeue message from lane
Check auto-compact threshold (pre-run, not middleware)
Invoke AgentRunner.run() with thread ID and message content
Catch ApprovalRequiredError — send approval UI to channel, await resolution
Catch InterruptSignalError — treat pending messages as new input
Handle followup depth tracking for self-continuation workflows
Process [SYSTEM] events from sub-agents and schedulers

AgentFactory manages the middleware list, the RuntimeModelOverride for /model switching (ephemeral — lost on restart), and create_stateless_agent() for cron/heartbeat runs (always uses the configured model, ignoring any runtime override).

WorkspaceLoader reads identity files and returns an AgentWorkspace with the fully assembled system prompt. ToolLoader discovers and imports @tool-decorated functions from the workspace's tools/ directory, auto-installing packages from tools/requirements.txt.

`openpaw/runtime/`¶

Runtime services that coordinate across a workspace's lifetime.

orchestrator.py — OpenPawOrchestrator launches workspace runners as concurrent asyncio tasks and coordinates shutdown
queue/lane.py — LaneQueue: FIFO with concurrency limit and per-session locking
queue/manager.py — QueueManager: routes messages across main, subagent, and cron lanes; exposes peek_pending() / consume_pending() for middleware
scheduling/cron.py — CronScheduler: APScheduler wrapper for YAML-defined and dynamically-scheduled jobs, fires in workspace timezone
scheduling/heartbeat.py — HeartbeatScheduler: configurable check-in intervals with active hours enforcement, pre-flight skip logic, and HEARTBEAT_OK suppression
scheduling/dynamic_cron.py — DynamicCronStore: persistence for agent-scheduled tasks
session/manager.py — SessionManager: maps session keys to active conversation IDs, persisted to .openpaw/sessions.json
session/archiver.py — ConversationArchiver: exports LangGraph checkpoint state to memory/conversations/ as conv_*.md + conv_*.json pairs
subagent/runner.py — SubAgentRunner: manages spawned agents with a semaphore, filtered tools, and session log writing

`openpaw/stores/`¶

File-backed persistence using threading locks and atomic writes (write to a tmp file, then os.rename). All stores are thread-safe and workspace-local.

TaskStore — TASKS.yaml CRUD with _load_unlocked/_save_unlocked pattern for atomic compound operations
SubAgentStore — subagents.yaml with full status lifecycle; auto-cleans entries older than 24 hours on initialization
DynamicCronStore — dynamic_crons.json; one-time tasks auto-cleanup after execution
ApprovalGateManager — in-memory state machine; not persisted (approvals are short-lived by design)

`openpaw/channels/`¶

External communication adapters. ChannelAdapter is the abstract base all adapters implement. The create_channel() factory in factory.py decouples WorkspaceRunner from concrete channel types — adding a new platform requires a new adapter file and a factory registration, nothing else.

The Telegram adapter handles sender allowlisting, voice/audio (delegated to WhisperProcessor), documents (delegated to DoclingProcessor), photo uploads, and inline keyboard callbacks for approval gates. The commands/ subdirectory contains CommandRouter and handler classes for all framework commands.

`openpaw/builtins/`¶

Extensible capabilities loaded conditionally based on prerequisites (API keys, Python packages). BaseBuiltinTool and BaseBuiltinProcessor define the extension interfaces. BuiltinRegistry is a singleton holding all registered builtins. BuiltinLoader filters by allow/deny lists and group membership, injects workspace config (including timezone) into each builtin's config dict, and activates only those with satisfied prerequisites.

Tools extend the agent's callable tool set: brave_search, browser (Playwright with accessibility tree), spawn, cron, task_tracker, send_message, send_file, followup, plan, elevenlabs.

Processors transform inbound messages before the agent sees them. Pipeline order is fixed by registration order in registry.py: file_persistence → whisper → docling. FilePersistenceProcessor always runs first, saving uploads to uploads/{date}/ and setting attachment.saved_path so downstream processors read from disk rather than memory.

Data Flows¶

Message Flow¶

A user message travels through the following stages:

Channel adapter — Receives the platform event, validates the sender against the allowlist, converts to a unified Message, and runs the inbound processor pipeline (file_persistence → whisper → docling).
Command router — Checks for a slash command prefix. Matched commands execute immediately and return a CommandResult without entering the queue. Commands run before processors intentionally — processors that prepend text would break slash command detection.
Queue manager — Assigns the message to the main lane, applies debouncing, and applies queue mode logic. In collect mode messages accumulate briefly; in steer or interrupt mode the manager flags the middleware.
Message processor — Dequeues the message, runs the pre-flight auto-compact check, and invokes AgentRunner.run().
Middleware stack — Before each tool call: QueueAwareToolMiddleware calls peek_pending() — if new messages arrived and the mode is steer, it skips remaining tools and injects pending messages as the next input; if the mode is interrupt, it raises InterruptSignalError. ApprovalToolMiddleware raises ApprovalRequiredError for gated tools.
Agent execution — The LangGraph ReAct loop calls tools, reads workspace files, and generates a response.
Response delivery — Returns through MessageProcessor to WorkspaceRunner, which sends it via the channel adapter. Token metrics write to token_usage.jsonl.

Scheduled Execution¶

Cron jobs and heartbeats bypass the queue entirely. The scheduler fires at the configured time (workspace timezone), builds a fresh stateless AgentRunner (no checkpointer, no conversation history), injects the prompt, and invokes the agent. Session logs write to memory/sessions/{cron,heartbeat}/ as three JSONL records: prompt, response, and metadata (tools used, token metrics, duration).

The delivery field controls output routing: channel sends directly to the configured chat, agent injects a [SYSTEM] event into the main lane queue, and both does both. Heartbeats add a pre-flight skip: if HEARTBEAT.md is trivial and no active tasks exist, the LLM call skips entirely and a skip outcome logs to heartbeat_log.jsonl.

Sub-Agent Flow¶

The main agent calls spawn_agent(task=..., label=...).
SubAgentStore creates a SubAgentRequest (status: pending) and persists it to subagents.yaml. The ID returns to the agent immediately.
SubAgentRunner acquires a concurrency semaphore (default: 8), updates status to running, and builds a fresh AgentRunner with a filtered tool set — spawn_agent, send_message, send_file, request_followup, and scheduling tools are excluded to prevent recursion and unsolicited messaging.
The agent executes the task. Session logs write to memory/sessions/subagent/.
On completion, the result stores (truncated at 50K characters), status transitions, and the semaphore releases.
If notify: true (default), a [SYSTEM] notification injects into the main lane via QueueMode.COLLECT, triggering a new agent turn where the main agent can call get_subagent_result(id) for the full output.

Approval Gate Flow¶

The agent calls a gated tool (e.g., overwrite_file).
ApprovalToolMiddleware creates a PendingApproval and raises ApprovalRequiredError.
MessageProcessor catches the error. Because LangGraph already checkpointed the AIMessage(tool_calls=[...]), AgentRunner.resolve_orphaned_tool_calls() injects synthetic ToolMessage responses to satisfy the state machine.
The channel sends an approval request (e.g., Telegram inline keyboard with Approve / Deny buttons).
The user responds. The channel invokes the registered approval callback, which calls ApprovalGateManager.resolve().
On approval: WorkspaceRunner re-runs the agent with the original message. The middleware calls check_recent_approval(), bypasses the gate, allows the tool to execute, then calls clear_recent_approval().
On denial: The agent receives [SYSTEM] The tool 'X' was denied by the user. Do not retry this action.
On timeout: default_action (deny or approve) applies automatically after timeout_seconds.

Configuration Resolution¶

Global defaults merge with workspace overrides, environment variables expand, and provider catalog entries resolve connection details before any workspace starts.

The merge is a deep dictionary merge: nested keys in agent.yaml override only the fields they specify; everything else inherits from config.yaml. A workspace that sets only model.temperature inherits the global model provider, API key, and all channel settings.

${VAR} substitution runs after merging. Any unresolved reference fails fast at startup with an error naming the missing variable and its source file. Provider catalog entries under providers: in config.yaml let multiple workspaces share connection details. The shorthand model: moonshot:kimi-k2.5 triggers resolution: moonshot maps to type: openai, api_key, and base_url in the catalog, producing a call to init_chat_model("openai:kimi-k2.5", ...) with those values. The user-visible display string stays moonshot:kimi-k2.5 in /status output.

See Configuration for the full field reference and provider catalog examples.

Design Decisions¶

Why LangGraph `create_react_agent`?¶

LangGraph provides a proven ReAct loop with native tool calling, conversation checkpointing via AsyncSqliteSaver, and first-class middleware support for tool interception. Building equivalent infrastructure from scratch would duplicate significant work with fewer correctness guarantees. LangChain's init_chat_model() handles multi-provider model instantiation behind a single interface, removing the need for per-provider adapter code and making runtime model switching straightforward to implement.

Why workspace isolation?¶

Running each workspace as a fully independent unit means one workspace's failure, model switch, or queue backlog cannot affect another. Isolation also enables distinct personalities, channels, and tool configurations per agent — a personal assistant workspace and a monitoring workspace coexist on the same host with zero shared state, separate conversation databases, and independent access control lists. Future horizontal scaling (distributing workspaces across machines) follows naturally from this design.

Why lane-based queueing?¶

Three lanes (main, subagent, cron) with independent concurrency limits prevent any category of work from starving another. Sub-agent tasks, which can run up to 8 concurrently, cannot block interactive user messages on the main lane. The design draws from OpenClaw (a predecessor project) whose command queue architecture proved the pattern in production. Per-lane session locking ensures a given user's messages execute in order even when concurrency is enabled.

Why the stability contract?¶

Enforcing one-directional dependencies keeps model/ free of framework imports. Models can be instantiated, serialized, and tested without pulling in LangGraph, APScheduler, or Telegram. If the framework changes its underlying orchestration library, business model code remains untouched. The stability contract also makes dependency graphs predictable — any import cycle signals a design problem that needs resolution before merging.

Why stateless scheduled agents?¶

Cron jobs and heartbeats use fresh agent instances with no checkpointer. Conversation history from user sessions would consume context window during unrelated scheduled runs and could produce confusing cross-contamination between interactive conversations and automated tasks. Scheduled agents communicate state through workspace files (HEARTBEAT.md, TASKS.yaml) which all execution contexts — including the main agent — can read and write.

Why middleware over hooks?¶

LangGraph's middleware API composes as a list passed to create_agent(middleware=[...]). Queue-aware behavior and approval gating are independent concerns that need to run in a specific order: queue-aware first so interrupt signals abort before approval prompts fire. Each middleware layer is a self-contained unit testable in isolation. New cross-cutting concerns (rate limiting, audit logging, per-tool timeouts) plug in without modifying agent, processor, or workspace code.

Extensibility¶

Adding a channel¶

Create a class extending ChannelAdapter in openpaw/channels/<platform>.py. Implement the required interface:

start() / stop() — initialize and tear down the platform connection
send_message(session_key, content) — deliver a text response
send_file(session_key, path, filename, caption) — deliver a file
send_approval_request(session_key, request) — display an approval UI
on_approval(callback) — register the approval resolution callback
register_commands(definitions) — register slash commands with the platform (e.g., Telegram bot command menu)

Convert inbound platform events to the unified Message model. Register the new type string in create_channel() in openpaw/channels/factory.py. WorkspaceRunner is fully channel-agnostic — no other changes are needed.

See Channels for the interface reference and a Discord example.

Adding a builtin tool or processor¶

Create a class extending BaseBuiltinTool or BaseBuiltinProcessor in openpaw/builtins/tools/ or openpaw/builtins/processors/:

Define a metadata property as a BuiltinMetadata instance with name, description, optional requires_api_keys, requires_packages, and group.
Implement get_langchain_tool() returning a list of BaseTool instances (for tools), or process_message(message, workspace) (for processors).
Register the class in openpaw/builtins/registry.py.

The loader handles conditional activation — if prerequisites are unmet, the builtin is silently skipped rather than raising an error.

See Built-ins for the full builtin reference and existing implementations.

Adding workspace tools¶

Drop a Python file containing @tool-decorated functions into a workspace's tools/ directory. ToolLoader discovers and imports them at startup, merging them into the agent's tool set alongside framework builtins. List any additional packages in tools/requirements.txt — the loader installs missing dependencies automatically before importing. Files prefixed with _ are skipped. Each workspace can carry a completely different tool set, enabling purpose-built agents without any framework changes.

Adding a command¶

Extend CommandHandler ABC with:

definition property — returns CommandDefinition (name, description, usage string)
handle(context: CommandContext) — executes the command and returns CommandResult

Register the handler in get_framework_commands() in openpaw/channels/commands/router.py. Commands fire before inbound processors and before queue assignment. CommandContext provides access to the workspace runner, agent factory, session manager, and channel — everything needed to implement any framework-level operation.

Security Model¶

Filesystem sandboxing¶

Agents have read/write access scoped strictly to their workspace directory. resolve_sandboxed_path() validates every path before any filesystem operation, rejecting absolute paths, ~, .., and any path that would escape the workspace root. The .openpaw/ directory is additionally protected — agents cannot read or write framework internals (checkpoint database, session state, token logs). resolve_sandboxed_path() is shared across FilesystemTools, SendFileTool, and inbound processors for consistent enforcement.

Tool access control¶

Agents only receive tools from enabled builtins and workspace-defined tools. API keys are resolved at startup from environment variables and passed to LangChain directly — they are never available as tool arguments or accessible to the agent. Sub-agents receive a filtered tool set with no recursion tools (spawn_agent), no unsolicited messaging tools (send_message, send_file), and no self-continuation tools (request_followup) to prevent unbounded autonomous behavior.

Channel access control¶

Each workspace maintains an allowed_users and allowed_groups allowlist. The channel adapter silently ignores messages from unauthorized senders before they enter the processor pipeline. Access control is per-workspace — the same Telegram user may be allowed in one workspace and blocked in another.

Secret management¶

Secrets never appear in config files directly. The ${VAR} expansion system reads from environment variables at startup. Workspace .env files load automatically and are excluded from version control via .gitignore. Unresolved ${VAR} references fail fast with a descriptive error rather than silently using empty values.

Testing¶

The test suite (1,100+ tests as of the current release) covers three levels:

Unit tests target individual components in isolation: config parsing and deep-merge logic, queue mode behaviors and lane concurrency, channel message format conversion, builtin registration and conditional loading, timezone utilities, filename sanitization, and sandbox path validation. Mock-heavy by design — no external services required.

Integration tests wire multiple components together with a mocked LLM: workspace loading and initialization, the full message flow from channel adapter to agent response, cron and heartbeat execution, sub-agent spawning and lifecycle, and approval gate round-trips. These tests use AsyncSqliteSaver with an in-memory database to validate checkpointing behavior without touching disk.

Browser tests use Playwright's test mode to validate the accessibility tree snapshot transformer, domain policy enforcement, and browser lifecycle (lazy init, session cleanup on /new and /compact). These run against static HTML fixtures rather than live websites.

Run the full suite with poetry run pytest. Individual modules: poetry run pytest tests/test_queue.py -v.
